特色
- Elliptical guide pin tip to minimize ferrule debris
- Exceeds TIA and IEC dimensional requirements for optimal performance
- Floating ferrule design ensures fiber contact integrity
- Highest precision SS guide pins
- Industry leading lowest loss Insertion Loss when used with MT Elite® Ferrules
- Quick and effective field pin reconfiguration without removing housing
- Removable housing for interferometry and rework
- Simple field polarity change with one-step insertion/extraction from Field Tool
应用
- Array fiber to single fiber breakouts and cassettes
- Array trunk cables
- FTTh (home) MDU cabling
- Parallel optic patch cables: SR-4, SR-8 & PSM4
- Qualified to GR-1435 service life
- Qualified to TIA-568.3-D
- Standards Compliance IEC 61754-7
- Standards Compliance TIA 604-5
- Structured cabling per TIA-942 & TIA-568
规格
型号
21753
品牌
MTP® PRO
类型
连接器
连接器类型
MTP Elite® 低损型
Key位方向
可切换极性-TIA-604-5
光纤类型
多模
类型
母头
弹簧力
10N
光纤数量
4+4, 1x12
外壳颜色
石楠紫
光缆类型
2.5 mm
工作环境
受控
尾部线缆类型
推拉护套2.0-3.0
样式
MPO
下载
产品图纸
文献资料
视频
材料清单套件
部件型号
描述
产品图纸
